20 litre Dehumidifier | Gree

20 litre Dehumidifier | Gree

Regular price R 5,350.00
Regular price R 5,500.00 Sale price R 5,350.00
Sale Sold out
Shipping calculated at checkout.

20 litre Dehumidifier | Gree

While a certain level of humidity is desirable for greenhouses or indoor gardens, too much humidity can lead to serious problems for your plants. If you are experiencing excess moisture in your grow room, you will need a dehumidifier.

                                                             Technical Specifications
Dehumidifiers
Sr No Parameter Unit Value
1 Model  -- GDN20BE-K5EBA1A GDN20BE-K5EBA1A
2 Product Code -- CK051037700 CK051037701
3 Power Supply Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases -- 1 1
4 Rated Dehumidification Capacity L/h 0.50 0.50
5 Rated Dehumidification Capacity L/D 12 12
6 Rated Dehumidification Capacity Pint/D 25.361 25.361
7 Rated Dehumidification Capacity kg/h 0.5 0.5
8 Power Input of Dehumidification Capacity L/h 0.83 0.83
9 Power Input W 350 350
10 Power Input of Dehumidification Capacity W 400 400
11 Current Input A 1.8 1.8
12 Rated Input W 530 530
13 Rated Current A 3 3
14 Air Flow Volume(H/M/L)  m3/h 170/145 170/145
15 Air Flow Volume(H/M/L)  CFM 100.045/�/85.333 100.045/�/85.333
16 Application Area m2 30~36 30~36
17 Sound Pressure Level (H/M/L)  dB (A) 39/37 39/37
18 Sound Power Level  ((H/M/L) dB (A) 53 53
19 Fan Type -- Centrifugal Centrifugal
20 Fan Diameter Length(D×L)  mm φ178.5X76.5 φ178.5X76.5
21 Fan Diameter Length(D×L)  inch
22 Fan Motor Speed r/min 960/840 960/840
23 Fan Motor Power Output W 5 5
24 Fan Motor RLA A 0.118 0.118
25 Fan Motor Capacitor  μF 1 1
26 Permissible Excessive Operating Pressure for the Discharge Side MPa 3 3
27 Permissible Excessive Operating Pressure for the Suction Side MPa 1.5 1.5
28 Maximum Allowable Pressure MPa 3 3
29 Set Humidity Range  % 30-80 30-80
30 Throttling Method -- Capillary Capillary
31 Climate Type -- T1 T1
32 Isolation -- I I
33 Moisture Protection -- IPX0 IPX0
34 Fuse Current A 3.15 3.15
35 Bucket Capacity  L 2.6/3.0 2.6/3.0
36 Control Type -- Electronic Electronic
37 Dimension (W×H×D)  mm 352×482×240 352×482×240
38 Dimension (W×H×D)  inch  13.858×18.976×9.449 13.858×18.976×9.449
39 Dimension of Carton Box (L×W×H) mm 389×283×510 389×283×510
40 Dimension of Carton Box (L×W×H) inch  15.315×11.142×20.079 15.315×11.142×20.079
41 Dimension of Package (L×W×H) mm 392×286×525 392×286×525
42 Dimension of Package (L×W×H) inch  15.433×11.26×20.669 15.433×11.26×20.669
43 Net Weight   kg 15.5 15.5
44 Gross Weight kg 17 17
45 Refrigerant -- R290 R290
46 Refrigerant Charge kg 0.08 0.08
47 Compressor Compressor Trademark  -- Danfu Danfu
48 Compressor Manufacturer -- Sichuan Danfu Environment Technology Co.,Ltd Sichuan Danfu Environment Technology Co.,Ltd
49 Compressor Model -- DFR60HF DFR60HF
50 Compressor Type -- Reciprocating Reciprocating
51 Compressor LRA.   A 11.49 11.49
52 Compressor RLA   A 1.8 1.8
53 Compressor Power Input W 318 318
54 Compressor Overload Protector -- HPA-110 HPA-110
55 Evaporator Evaporator Form  -- Aluminum Fin-copper Tube Aluminum Fin-copper Tube
56 Evaporator Pipe Diameter mm φ7 φ7
57 Evaporator Pipe Diameter inch
58 Evaporator Row-fin Gap mm 2-1.4 2-1.4
59 Evaporator Coil Length (L×D×W)  mm 238X25.4X190.5 238X25.4X190.5
60 Evaporator Coil Length (L×D×W)  inch
61 Condenser Condenser  Form  -- Aluminum Fin-copper Tube Aluminum Fin-copper Tube
62 Condenser  Pipe Diameter  mm φ5 φ5
63 Condenser  Pipe Diameter  inch
64 Rows-fin Gap mm 2-1.4 2-1.4
65 Condenser  Coil Length (L×D×W)   mm 238X22.8X190.5 238X22.8X190.5
66 Condenser  Coil Length (L×D×W)   inch
67 Loading quantity  Loading Quantity
( 20’ Container )
unit 472 472
68 Loading Quantity
( 40’ Container )
unit 976 976
69 Loading Quantity
( 40’ High Cube Container )
unit 1218 1218
Dehumidifiers Function
70   Water Level Indicator/Location NO NO
71 Removable Bucket/Location YES YES
72 External Drain Connector YES YES
73 Easy Roll Casters  YES YES
74 Auto Swing(Vertical Auto Swing) NO NO
75 Auto Swing(Horizontal Auto Swing) NO NO
76 Auto Swing(4-Dimension Swing) NO NO
77 Water Full Indicator YES YES
78 Air Flow   NO NO
79 Memory   YES YES
80 Auto Fan NO NO
81 Quiet Design YES YES
82 I Feel NO NO
83 Function Related with PCB Timer Feature YES YES
84 Automatic Defrost YES YES
85 Real-time display of ambient humidity YES YES
86 Tank Filled Protection YES YES
87 Self Diagnosis  YES YES
88 Function  Unrelated with PCB Several Optional Filters (Active Carbon, Catechin, Anti-mildew,Electrostatic Dedust,Silver Ion Sterilizing Material,Cold Catalyst ,Photocatalyst  etc.)    Optional Optional
89 Display Mode LCD      NO NO
90 LCD Back Light    NO NO
91 LED
